| High speed double spindle motor | 7.5KW*1 / 5.5KW*1 |
| X-axis servo motor | 2.5KW |
| Y-axis servo motor | 1KW*2 |
| Z-axis servo motor | 3KW |
| A-axis servo motor | 1KW |
| C-axis servo motor | 1KW |
| Maximum working length | 2600mm, the width of the milling end is 800mm |
| Processing efficiency | 5-6 coffin per day (cover wall milling ends + back, not including appearance) |
| Machining accuracy | ±0.1mm |
| Equipment power | 22.5KW |
| Maximum service power | About 17KW |
| Equipment weight | 4000kg |
| Equipment size | （L）5500mm*（W）3100mm*（H）2800mm |
| The above parameters are for reference only, the actual product will change according to the processing performance requirements. | |
This machine manual loading and unloading, four processes five axis linkage processing, platform clamping, not landing a five-sided processing molding, processing the two ends of the life and the back, at the same time processing 2 back, in addition to add 2 back quick clamping.
